Low-Voltage Bundled Construction
Insulated conductors are bundled for LV overhead distribution and service connection routes.
Low Voltage ABC Cable
Low Voltage ABC Cable for low-voltage aerial bundled cable distribution routes.
Low Voltage ABC Cable is reviewed for overhead bundled distribution routes where conductor size, insulation system, messenger support and utility standard need to match the project voltage class.
Product Overview
Low Voltage ABC Cable should be selected according to the actual project route, not by product name alone. Before quotation, review voltage grade, core arrangement, messenger or neutral design, insulation system and utility standard. Datasheet wording, compliance documents and final supply notes should stay aligned with the selected standard and installation conditions.
Applications
- overhead distribution network construction
- rural electrification and utility feeder upgrades
- pole-mounted secondary or medium-voltage routes
- projects requiring bundled insulated overhead cable supply
Construction
Aerial bundled cable construction with insulated phase conductors and messenger or neutral arrangement according to voltage grade. Final conductor material, insulation, core count and support design should follow the required standard.
Marking on Cable
FARWALK CABLE – Low Voltage ABC Cable – [standard] – [voltage] – [size] – [year] – [meter mark]
Cable Identification
- Core color or numbering can be reviewed according to utility practice.
- Outer insulation color and printing should follow the inquiry or project standard.
Standards
- IEC 60502-1
- BS 7870-5
- AS/NZS 3560.1
- SANS 1418 where required
- project utility requirements
Main Features
Weather-Resistant Overhead Use
Designed for outdoor overhead routes where UV exposure, messenger support and utility standards are reviewed.
Phase Arrangement Options
For Low Voltage ABC Cable, duplex, triplex, quadruplex or multicore configurations should match the service connection requirement.
Product Selection Guide
Voltage and Route
Separate LV ABC, MV ABC, service drop, covered conductor and tree wire before selecting construction.
Phase Arrangement
Confirm duplex, triplex, quadruplex, single-core or bundled configuration according to the service route.
Messenger / Neutral
Review messenger material, neutral conductor, full neutral or self-supporting design with the utility requirement.
Weather and Fittings
Check UV exposure, temperature, fittings, span length and local utility standard before final selection.
Technical Data Overview
| Phase (mm2) |
Cores | Insul. (mm) |
DC Res. (Ohm/km) |
Current (A) |
V. Drop | Neutral / Msg. (mm2) |
OD (mm) |
Weight (kg/km) |
| 16 | 3 | 1.0 | 1.91 | 61 | 4.05 | 25 | 19.0 | 290 |
| 25 | 3 | 1.2 | 1.20 | 84 | 2.54 | 25 | 23.2 | 400 |
| 35 | 3 | 1.2 | 0.868 | 104 | 1.84 | 25 | 25.6 | 500 |
| 50 | 3 | 1.4 | 0.641 | 129 | 1.36 | 35 | 30.0 | 680 |
| 70 | 3 | 1.4 | 0.443 | 167 | 0.95 | 50 | 34.9 | 920 |
| 95 | 3 | 1.6 | 0.320 | 209 | 0.69 | 70 | 40.6 | 1270 |
| 120 | 3 | 1.6 | 0.253 | 246 | 0.55 | 70 | 44.1 | 1510 |
| 150 | 3 | 1.8 | 0.206 | 283 | 0.46 | 95 | 49.2 | 1870 |
| 185 | 3 | 2.0 | 0.164 | 332 | 0.37 | 120 | 54.9 | 2340 |
